| Printable Area |
Up to 16” x 19.6” / 40.6 cm x 49.8 cm with optional large platen
|
| Print Head Technology |
Ricoh piezo-electric drop-on-demand inkjet |
| Ink Chambers/Nozzles per Chamber |
4 Ricoh print heads
8 channels/192 nozzles per channel |
Typical Print Speeds
(10" x 8" graphic, light garment) |
Speed: 27 seconds
Fine: 42 seconds |
| Resolution Settings |
Super Speed: 600 x 300 dpi/2 pass
Speed: 600 x 600 dpi/4 pass
Fine: 600 x 600 dpi/8 pass
Extra Fine: 600 x 600 dpi/9 pass
Super Fine: 1200 x 1200 dpi/16 pass
|
| Ink |
Genuine Ricoh-approved direct-to-garment water-based pigmented CMYK and white ink |
| Ink Delivery System |
Advanced closed-loop delivery system; Auto ink circulation system for white channels |
| Printable Substrates |
100% Cotton and high-cotton blends; 100% light poly, up to 50/50 dark poly wood and canvas. Hats, shoes, and other extended media options are coming soon
|
| Table Height Adjustment |
Precision manual table height adjustment up to 1.2"/3.0 cm |
| Maintenance Features |
Precise ink monitoring, auto ink maintenance system, automated print head cleaning, power purge system to help fill and remove ink from the system
|
| Operating Environment |
59F/15C to 90F/32C
|
| Connectivity |
Supports USB drive and Ethernet |
| Electrical Requirements |
100/120VAC 50-60Hz, 0.65A max, 70 watts
|
| Dimensions |
19.4”H x 52.2”L x 33.9”W
|
| Weight |
242.5 lbs (110 kg) |
| Curing Temperatures and Times - Heat Press (conveyor times vary) |
Light shirt (CMYK only): 356F/180C, 40 seconds
Dark shirt (white ink): 330F/165C, 90 seconds |
| Pretreatment |
Genuine Ricoh-approved pretreatment formulas. Use the included HVLP Wagner power or automatic sprayer in a separate room from your printer. |
| Standard Table |
Medium (Included)
12.6" x 18" / 32 x 45.7 cm |
| Optional Platens |
Large
16" x 19.6" / 40.6 x 49.8 cm
Small
10.5" x 13" / 26.6 x 33 cm |
| Required Operating System |
Windows 10 (Pro, Enterprise), Windows 11, Windows Server 2016, Windows Server 2019
|
| Recommended Graphics Application |
PhotoShop/Illustrator/CorelDraw/Action Illustrated
|
| Supported File Types |
TIFF, PNG, JPG, BMP, PSB, PSD (PDF, PS, EPS are supported for non-bundle editions)
|
| Minimum Processor and Memory |
CPU: Intel Core i3-2100 / AMD Athlon II X2 340
RAM: 4GB
|
| Computer Storage |
Free disc space: 120GB
|
| Display Resolution |
1280 x 1024
|
